GPU AD102-300
Process 4
CUDA Cores 16384
Idle Board Power N/A
Max Board Power 550W
Power Connectors PCIe Gen5 16-pin connector *2
Idle GPU Temperature N/A
Max GPU Temperature N/A
Size 24GB
Type GDDR6X
Memory Width 384-bit
Memory Bandwidth 1008
Interface PCI-E 4.0
Dimensions(with Bracket) 360*159*77
Dimensions(without Bracket) 344*144*77
Boost Clock 2595
Over Clock O
Memory Clock (effective) 21
Over Clock ×
1st output DisplayPort 1.4a
2nd output DisplayPort 1.4a
3rd output DisplayPort 1.4a
4th output HDMI 2.1a
5th output
Edge N/A
Software SLI / Crossfire ×
FAN 2*112mm, 1*92mm
Slot 3,8
FAN Control O
Idle Noise Level (decibel) N/A
MAX Noise Level (decibel) N/A
Heatpipes / VC 4*8mm, 5*6mm, VC
RGB Front, Top and back plate
Other special features 1)1-Click Sync Pro
DirectX DirectX 12
Windows support Windows 10/11 64-bit
Minimum Power Supply 1000W
